CAPTURE PRECISION. EXECUTE PERFECTION.
In ballistics there is no room for error. The Xero C2 chronograph is the source you can trust. It builds on the success of its predecessor with a faster shot processor and improved features for an experience you won’t find anywhere else.
VERSATILE AND RELIABLE PERFORMANCE
The chronograph will reliably pick up your shots, thanks to the accurate sensor. The device can measure projectile speeds from 100 fps to 5,000 fps for bullets, arrows, slugs, airsoft BBs and more.
RESUME YOUR SESSION
Shoot different firearms while the barrel cools off, or test multiple bows or arrows with the resume sessions feature — which keeps data separate for each.
SMARTWATCH INTEGRATION
With smartwatch integration, you get easy access to your data while you maintain your shooting position. Connect your compatible Garmin smartwatch to access session controls, view live data and import muzzle velocity into the onboard Applied Ballistics® solver.
RAPID-FIRE SUPPORT
The faster processing speed supports rapid fire of up to 10 shots per second, depending on projectile velocity.
SHOTVIEW™ APP
Keep track of your shots, measure deviation, manage sessions, view live data and more when paired with the ShotView app on your smartphone.
BUILT TO ENDURE
Reinforced housing is designed to withstand recoil when mounted to your rifle and is water-resistant with an IPX7 water rating.
AB INTEGRATION
The Xero C2 chronograph works with the Applied Ballistics app to pull muzzle velocity straight into the AB Quantum app.
EASY TO OPERATE
Indoor and outdoor operation is simple, thanks to the backlit display and button-operated design.
SIMPLE SETUP
Turn it on. Set it up. Point it in the direction of fire, and shoot. Yeah, really.
RECHARGEABLE BATTERY
With battery life up to 2,000 shots or up to 6 hours, you can take your time at the range.
SUPPRESSOR SUPPORT
The device picks up shots from suppressed firearms and firearms with muzzle brakes or compensators.
MULTIPLE DEVICE SUPPORT
Start a session on one device, and continue it on another device with the ShotView app.
SPECIFICATIONS
|
General
|
| Dimension |
3.03" (77 mm) x 2.38" (60.5 mm) x 1.36" (34.44 mm) without tripod
5.1" (130 mm) x 4.5" (115 mm) x 5.5" (138.5 mm) with tripod |
| Weight |
123.2 g without tripod
178.2 g with tripod
|
| Water rating |
IPX7 |
| Display Type |
sunlight-visible, transflective, monochrome |
| Display Size |
1.3" x 1.7" (33 mm x 44 mm), 2.2" diagonal (55 mm) |
| Display resolution |
240 x 320 pixels |
| Battery Type |
internal rechargeable lithium-ion battery |
| Battery life |
up to 6 hours
|
| Operating range |
-10° C to 55° C (14° F to 131° F) |
| Memory/History |
200 sessions before a ShotView™ app sync is required to save data to phone |
| Interface |
USB-C |
|
Daily Smart Features
|
| Connectivity |
BLUETOOTH® technology |
| Mobile app |
ShotView™ app |
|
Chronograph Features
|
| Tracks rifles up to 5000 FPS |
|
| Tracks bows and crossbows up to 600 FPS |
|
| Track pistols up to 5000 FPS |
|
| Tracks air rifles up to 2000 FPS |
|
| Tracks airsoft up to 1000 FPS |
|
| Track other projectiles up to 5000 FPS |
|
| Calculates kinetic energy at muzzle |
|
| Calculates power factor |
|
| Calculates extreme spread |
|
| Calculates standard deviation |
|
| Calculates string average |
|
| Delete shots in string |
device or app |
| Decimal precision |
|
| Add individual shot notes |
yes (on ShotView™ app) |
| Add session notes |
yes (on ShotView™ app) |
| Mark shots with clean/cold bore |
yes (on ShotView™ app) |
| Exclude shot from average and standard dev calculations |
device or app |
| Tripod compatibility |
yes (¼-20 thread compatible) |
WHAT'S IN THE BOX
- Xero C2 chronograph
- Protective cover
- 1/4-20 thread tripod
- Charging/data cable
- Documentation
